Product Overview
ZISHENG 10kVA Single Phase Pad Mounted Transformer is a high-performance outdoor distribution transformer designed for safe and reliable power distribution applications. It is mainly used to step down medium voltage electricity to low voltage power for residential, commercial, industrial, and utility users.
The transformer adopts a compact pad-mounted structure with underground cable connection, providing excellent safety, environmental protection, and convenient installation. It is suitable for modern power distribution systems that require high reliability, low maintenance, and stable operation.
Manufactured with advanced production technology and strict quality control, ZISHENG Single Phase Pad Mounted Transformer delivers excellent electrical performance, energy efficiency, and long-term operational reliability.
Technical Specifications
| Item |
Description |
| Product Type |
Single Phase Pad Mounted Transformer |
| Rated Capacity |
10kVA |
| Phase |
Single Phase |
| Frequency |
50Hz / 60Hz |
| Cooling Type |
ONAN (Oil Natural Air Natural) |
| Installation Type |
Outdoor Pad Mounted |
| Insulation Medium |
Mineral Oil / Optional Natural Ester Fluid |
| High Voltage |
Customized |
| Low Voltage |
Customized |
| Temperature Rise |
65℃ |
| Winding Material |
Aluminum / Copper Optional |
| Core Material |
High Quality Grain-Oriented Silicon Steel |
| Enclosure Material |
Carbon Steel / Stainless Steel Optional |
| Protection Level |
Outdoor Weatherproof Design |
Main Features
1. High Energy Efficiency and Low Loss Design
The transformer uses high-quality grain-oriented silicon steel core and optimized electromagnetic design to reduce no-load and load losses. The improved efficiency helps customers reduce energy consumption and operating costs throughout the transformer’s service life.
2. Reliable Safety Protection
The pad-mounted cabinet adopts a secure and tamper-resistant structure to prevent unauthorized access. Equipped with reliable protection components, the transformer ensures safe operation in outdoor distribution environments.
3. Strong Environmental Adaptability
The robust tank structure and protective coating provide excellent resistance against moisture, corrosion, and harsh weather conditions. It can operate stably in environments with high temperature, high humidity, and outdoor exposure.
4. Excellent Overload and Short-Circuit Resistance
The optimized winding structure and high-strength insulation system improve mechanical strength and thermal performance, allowing the transformer to withstand overload conditions and short-circuit impacts.
5. Compact and Easy Installation
The integrated pad-mounted design reduces installation space requirements and simplifies connection with underground cable systems, making it ideal for urban and industrial distribution networks.
6. Customizable Configuration
ZISHENG supports customized solutions according to different project requirements, including:
- Rated voltage
- Frequency
- Winding material
- Insulation oil type
- Protection accessories
- Terminal configuration
- Special technical standards
Standard Configuration
- High-quality silicon steel core
- Oil-immersed cooling system
- Outdoor protective enclosure
- High-voltage bushings
- Low-voltage bushings
- Pressure relief device
- Oil level indicator
- Temperature monitoring device
- Grounding terminal
- Lockable cabinet structure
Optional Accessories
- Copper winding design
- FR3 natural ester insulation fluid
- Stainless steel enclosure
- Dual voltage system
- Internal backup fuse
- High voltage switch
- Additional monitoring devices
- Customized connection terminals
Application Areas
ZISHENG 10kVA Single Phase Pad Mounted Transformer is widely applied in:
- Residential communities
- Commercial buildings
- Industrial facilities
- Utility distribution networks
- Renewable energy projects
- Solar power systems
- Infrastructure projects
- Mining and remote power supply systems
- Urban underground cable distribution networks
Quality Assurance
Each ZISHENG Pad Mounted Transformer undergoes strict quality inspections and electrical testing before shipment to ensure reliable performance and compliance with customer requirements.
Testing includes:
- Insulation resistance testing
- Transformer ratio testing
- No-load loss testing
- Load loss testing
- Dielectric strength testing
- Leakage inspection
- Functional performance verification
With professional manufacturing capability, strict quality management, and international export experience, ZISHENG provides dependable transformer solutions for power distribution projects worldwide.
10kVA Single Phase Pad Mounted Transformer FAQ
Q1: What is a 10kVA Single Phase Pad Mounted Transformer?
A: A 10kVA Single Phase Pad Mounted Transformer is an outdoor distribution transformer designed to reduce medium voltage electricity to low voltage power for residential, commercial, and industrial applications. It is installed on a concrete pad and connected through underground cables, providing a safe and reliable power distribution solution.
Q2: What are the main applications of this transformer?
A: The 10kVA Single Phase Pad Mounted Transformer is commonly used in:
- Residential communities
- Commercial buildings
- Industrial facilities
- Utility distribution systems
- Renewable energy projects
- Underground power networks
- Infrastructure and construction projects
Q3: What are the advantages of ZISHENG 10kVA Single Phase Pad Mounted Transformer?
A: The main advantages include:
- High energy efficiency and low power loss
- Reliable insulation and protection performance
- Strong overload and short-circuit resistance
- Compact structure and easy installation
- Long service life
- Stable operation in harsh outdoor environments
- Customized design according to project requirements
Q4: What voltage levels are available?
A: The primary and secondary voltage ratings can be customized according to customer requirements and local power grid standards. ZISHENG can provide different voltage configurations to meet various international project needs.
Q5: What cooling method does this transformer use?
A: The standard cooling method is ONAN (Oil Natural Air Natural), which uses natural oil circulation and air cooling to maintain safe operating temperatures and improve reliability.
Q6: What materials are used for the transformer?
A: ZISHENG 10kVA Single Phase Pad Mounted Transformer uses high-quality materials, including:
- Grain-oriented silicon steel core for low losses
- Aluminum or copper windings according to requirements
- High-strength steel tank structure
- High-quality insulation oil for reliable electrical performance
Q7: Can the transformer be customized?
A: Yes. ZISHENG provides customized transformer solutions based on project specifications, including:
- Voltage levels
- Frequency (50Hz/60Hz)
- Winding materials
- Oil type
- Cabinet structure
- Protection accessories
- Special technical requirements
Q8: Is the transformer suitable for outdoor installation?
A: Yes. The transformer is designed for outdoor pad-mounted installation. Its protective enclosure provides resistance against weather conditions, moisture, corrosion, and environmental challenges, ensuring stable operation in outdoor environments.
Q9: What quality tests are performed before delivery?
A: Each transformer undergoes strict inspection and testing before shipment, including:
- Ratio testing
- Insulation resistance testing
- No-load loss testing
- Load loss testing
- Dielectric strength testing
- Leakage inspection
- Electrical performance verification
These tests ensure product reliability and compliance with customer requirements.
Q10: What certifications and standards can ZISHENG transformers meet?
A: ZISHENG transformers can be manufactured according to international standards and customer project requirements, including relevant electrical safety, performance, and efficiency requirements for different markets.
Q11: What is the delivery time for a customized transformer?
A: Delivery time depends on transformer specifications, order quantity, and production schedule. ZISHENG provides professional production planning and communication to ensure timely delivery for each project.
Q12: Why choose ZISHENG as a transformer supplier?
A: ZISHENG has professional transformer manufacturing capabilities, advanced production facilities, strict quality control systems, and international export experience. The company provides reliable transformer products, technical support, customized solutions, and complete service for global power distribution projects.
